Main screen

The Main application screen has a map preview in the background.

The main application screen can be divided into these zones:

  1. System status bar,
  2. Control bar,
  3. Live video preview (Switch cameras on top-right buttons),
  4. Menu,
  5. Telemetry window,
  6. Vehicle status window,
  7. Live RC (pilot) location,
  8. Home point location,
  9. Drone's current location.
